Dahua Face Recognition Door Station (DHI-VTO6531H)
- 4.3 inch IPS display; screen resolution 800×480
- 2MP CMOS; true WDR
- Face-camera distance: 0.3 m–2 m; human height: 1.1 m–2.4 m (lens ground distance: 1.4 m)
* Harga hubungi kami *
SKU:
DHI-VTO6531H
Kategori: Access Control, Access Control & Time Attendance, Dahua
Tag: Access Control, Dahua
Deskripsi
System |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Main Processor | Embedded processor | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System | Embedded Linux operating system | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Button Type | Touch button | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | SIP; P2P; IPv4; FTP; UPnP; DNS; DDNS; RTSP; RTP; TCP; UDP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 4GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 1GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Basic |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display Screen | 4.3 inch IPS screen | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 800×480 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Camera | 1/2.7″ 2MP CMOS high definition, low illumination, white illuminator and IR illuminator | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View | Horizontal: 87.42°; vertical: 46.48 °;
diagonal: 104.13° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 4.0 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Aperture | F1.6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
WDR | 120dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Noise Reduction | 3D noise reduction | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Resolution | Main Stream: 720p, sub stream: 1080P | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Frame Rate | Main Stream (720P@25fps), sub stream (1080P@25fps) Main Stream (720P@30fps), sub stream (1080P@30fps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Bit Rate | 256Kbps–2048Kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Light Compensation | Auto white light Auto IR light | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Day/Night | ICR auto switch | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711u | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | Built-in speaker | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Mode | Full duplex communication | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Enhancement | Echo suppression and cancellation/digital noise reduction | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Bit Rate | 16KHz, 16Bit | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Function |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Communication Mode | Full digital | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Unlock Mode | Card/Remote/Password/Face unlock | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Card Reading Type | IC card | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection | Video motion detection | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Auto Snapshot | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Leave Videos or Text Messages | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Web Configuration | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Performance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Card Reading Distance | 1cm–5cm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Issue Card Locally | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Height Range | 1.1m–2.4m is recommended | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Distance | 0.3m–2cm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Configuration | Recognition threshold Facial profile angle | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Verification Accuracy | 99.5% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Recognition Time | 0.2s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing Material | PC+ABS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Capacity |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Card | 10,000 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Face Image | 10,000 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS-485 | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Wiegand | 1 input port, 1 output port | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electric lock | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input | 2 (Digital quantity) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | 2 (Digital quantity) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Output | 1 12V/100mA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Exit Button | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Door Status Detection | 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lock Control | 1, normally open by default | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | 1 RJ-45 10Mbps/100Mbps self-adaptive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Tamper | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Unlock Password Mode | User password/public password/duress password | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Color | Silver | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply Mode | DC 12V2A | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | Optional | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation | Surface mount and Flush mount | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | CE/FCC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Accessory | Optional | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 388.5mm×145.5mm×43.5mm (15.30″×5.73″×1.71″) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection Grade | IP65 (silicone sealant is needed, see the quick start guide) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | -30°C to +60°C (-22°F to +140°F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | 10RH%–90RH% (non-condensing) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Altitude | 86kPa–106kPa | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | ≤5W (standby), ≤18W (working) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight | 1.0 kg (2.20 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight | 1.29 kg (2.84 lb) |
